Tabletop ACF Bonding System

Tabletop ACF Bonding System

LD-02 Tabletop ACF Laminator


LD-02 is a tabletop ACF laminator, which can laminate ACF up to 60mm length and handle a wide variety of works including LCD, FPC, and PWB. Operator can exchange tools and jigs easily.

Model LD-02　Tabletop ACF Laminator
Process FOB、FOG、FOF、COG、COB、COF

LD-03 Tabletop ACF Laminator


LD-03 is a tabletop ACF laminator, which can laminate ACF up to 100mm length and handle a wide variety of works including LCD, FPC, and PWB. Operator can exchange tools and jigs easily.

Model LD-03　Tabletop ACF Laminator
Process FOB、FOG、FOF、COG、COB、COF

BD-01 Tabletop Heat Bonder (Constant heater)


BD-01 is a tabletop constant heat bonder which can bond up to 60mm width. Operator can exchange tools and jigs easily and handle a wide variety of works.

Model BD-01　Tabletop Heat Bonder (Constant heater)
Process FOB、FOG、FOF、COG、COB、COF

BD-02 Tabletop Heat Bonder (Pulse heater)


BD-02 is a tabletop pulse heat bonder which can bond up to 20mm square(standard heat tool size). Operator can exchange tools and jigs easily. Other-sized heater is available (option).

Model BD-02　Tabletop Heat Bonder (Pulse heater)
Process FOB、FOG、FOF、COG、COB、COF

BD-03 Tabletop FPC Heat Bonder with CCD


BD-03 is a tabletop FPC bonder. Operator aligns FPC manually by adjusting a stage position in XYZ-axis direction. Operator can exchange tools and jigs easily and handle a wide variety of works.

Model BD-03　Tabletop FPC Heat Bonder with CCD
Process FOB、FOG、FOF

HBM-10 FPC Heat Bonder


A compact and simple low-priced constant heat bonding machine.
It can be bonded up to a range of 100 x 5 mm.


Model HBM-10　FPC Heat Bonder
Process FOB、FOG、FOF

OH-251 Tabletop FPC Heat Bonder for large FPC


OH-251 is tabletop constant heat bonder which can bond
 up to a range of 250 x 60 mm.

Model OH-251 Tabletop FPC Heat Bonder for large FPC
Process FOB, FOG
Specifications Tool size Max. 250 mm (W) x 60 mm (D)
Stage size Max. 230 mm (W) x 100 mm (D)
Thrust force 700 ~ 3000 [N]
Setting Temperature RT ~ 350 ℃ ± 5 ℃
Cushioning material: Silicon sheet automatic winding (left to right)
