semi-automatic ACF Bonding System

ACF Semi-Automatic

LS-02Z Semi-Automatic ACF Laminator


LS-02Z is an ACF laminator which laminate ACF onto multiple positions of a work or onto multiple works. The equipment handles works with carrier and laminates ACF continuously at one cycle, which increases your productivity.

Model LS-02Z ACF laminator
Process FOB、FOG、FOF、COG、COB、COF

MS-04Z　Semi-Automatic FPC/IC Mounter


MS-04Z is a mounter which aligns and mounts FPC onto works automatically. It handles works with carrier and aligns and mounts FPC onto them continuously, which increases your productivity.

Model MS-04Z　 Mounter
Process FOB、FOG、FOF、COG、COB, COF

BS-03Z Semi-Automatic ACF Heat Bonder (Constant heater)


BS-03Z is a constant heat bonder with multiple heads.
It can bond maximum 4 works in a row at the same time, which increases your productivity and suitable for mass production.


Model BS-03Z　ACF Heat Bonder (Constant heater)
Process FOB、FOG、FOF、COG、COB、COF

BS-04Z　Semi-Automatic ACF Heat Bonder (Pulse heater)


BS-04Z is a pulse heat bonder with multiple heads.
It can bond maximum 4 works in a row at the same time, which increases your productivity and suitable for mass production.


Model BS-04Z　ACF Heat Bonder (Pulse heater)
Process FOB、FOG、FOF、COG、COB、COF

ME-02　Semi-Automatic　FOG Bonder


Semi-automatic FOG machine ideal for medical X-ray panels.
Multiple FPCs are automatically aligned and bonded continuously on one side of the panel.

Model ME-02 FOG Bonder
Process FOG
